Shredders & Hammermills
11 kW Single-Shaft Shredder with Hydraulic Pusher
- Compact single-shaft shredder for plastics, wood waste, packaging and recyclables
- 11 kW motor with 300 mm rotor, 650 mm long
- 24 moving knives and 2 fixed knives
- Replaceable screen controls particle size – 20 mm fitted as standard
- Hydraulic pusher, PLC control and automatic reverse against blockages
- Motor
- 11 kW
- Rotor
- 300 mm diameter × 650 mm long
- Knives
- 24 moving, 2 fixed
- Screen
- 20 mm standard, others available
- Pusher
- Hydraulic
- System
- PLC with automatic reverse
Product information
This compact single-shaft shredder produces an even output by holding material against the rotor until it passes through the screen. Change the screen to change the particle size.
Features
- Hydraulic pusher for steady feeding
- Automatic reverse frees jams and reduces downtime
- PLC control for simple operation
- Other screen sizes available
Frequently asked questions
How do I change the output size?
Fit a different screen; 20 mm is standard.
I need more capacity. What are my options?
The Model 600 single-shaft shredder with a 22 kW motor.
Full specifications
Machine
| Motor | 11 kW |
| Rotor | 300 mm diameter × 650 mm long |
Cutting
| Knives | 24 moving, 2 fixed |
| Screen | 20 mm standard, others available |
Feeding
| Pusher | Hydraulic |
Control
| System | PLC with automatic reverse |
